IAC 250 Mini Sound Booth
£4,595.00 – £5,600.00 ex. VAT
The 250 Series Acoustic Booth provides a controlled acoustic environment in which audiological examinations can be undertaken efficiently and at low cost – fully complying with BS EN ISO 8253-1. The booths are available in two variants for the mounting of the door and installation of the window. Please make a selection for more details.
NOTE: This item is supplied via curbside delivery only. Due to the size of this product, there is a standard £400 delivery fee for mainland UK addresses (applied at checkout).
If you have any questions, please contact P&A Medical on +44 1204 676180 before completing checkout.
Add-ons
Description
IMPORTANT: The IAC 250 Mini Sound Booth is available via curbside delivery ONLY. Movement of individual panels and the assembled unit requires 2 or more people.
The compact design of the booth ensures that it will pass easily through any standard doorway, and fitted castors make it completely mobile.
Full equipped with a silenced ventilation system, lighting, seating, shelf and jack-panel audiometer connections, the 250 series sound shelter is ready to use within minutes of delivery.
IDEAL FOR:
- Industrial Audiometry
- Pure-tone Threshold Audiometry (air and bone)
- Speech Audiometry (through earphones)
- Psychological Data Recording
- Complies fully with BS EN ISO 8253-1
- Supplied fully assembled or in ‘kit’ form.
Technical Specification of the acoustic sound booth
DIMENSIONS
Outside dimensions: 710mm wide x 981mm deep x 1943mm high. Includes castors.
Internal dimensions: 604mm wide x 860mm deep x 1680mm high.
Weight: 295kg net, 322kg shipping weight.
CONSTRUCTION
53mm thick, Noiseshield panels – plain galvanized steel exterior surfaces and perforated galvanized steel interior surfaces.
DOOR
One door 604mm wide x 1680mm high (clear opening) Noise-Lock door. For complete safety and effective acoustic control, self-aligning magnetic compression seals are mounted on the top, bottom and sides of the door leaf.
WINDOW
One double glazed unit comprises of 6mm thick safety glass fitted in aluminium frames; clear view 736mm high x 584mm wide. The lower portion of the window has a frosted section.
JACK-PANEL
Completely pre-wired flush-mounted jack panel consists of three 6mm 3 pole sockets and two 6mm 2 poles sockets.
VENTILATION
Ceiling panel contains a Tranquil – Air all-in-one silenced forced ventilation system.
LIGHTING
LED maintenance free, ceiling recessed lighting (12v).
ELECTRICAL
Separate switches operate the ventilation system and the lamp. A 13 amp switched socket is positioned adjacent to the jack panel for the operation of an audiometer. A 300mm long drop cord with fitted 13-amp plug is provided for connection to power.
SHELF
Outside mounted folding shelf for audiometer, 705mm long x 457mm deep with durable powder-coated finish
SEAT
Fixed internal bench seat 460mm deep with black moulded finish for comfort.
FLOOR
Covered with foam backed nylon carpet.
NOISE REDUCTION
Noise reduction is defined as the measured difference between the sound pressure levels in a reverberant room, outside the booth and inside the booth.
PREFERRED OCTAVE BAND CENTRE FREQUENCY Hz 125 250 500 1000 2000 4000 8000
NOISE REDUCTION Db 18 32 38 44 51 52 50
INSTALLATION
Booth is supplied pre-assembled, finish decorated and ready to use. Also available in kit form for restricted access.
PAINT FINISH
Off-white powder paint, RAL 9002 matt. Interior and exterior.
To request a quotation for an acoustic sound booth, including delivery and set-up, please contact our sales team on 01204 676180 today, or visit our contact us page.
Additional information
| Weight | 322 kg |
|---|---|
| Dimensions | 71 × 71 × 194.3 cm |
